CP903083 3V 6400mAh Lithium Manganese Soft Pack Battery: High-Capacity Power for Decades of Unattended IoT Operation
- Omnergy
- 中国
- 15 days
- 1000 million per year
Source the high-energy Omnergy CP903083 3V 6400mAh primary lithium soft pack battery. Slim 9.2mm profile, -40°C to +60°C performance, <2% annual self-discharge. Engineered for long-term GPS asset tracking and industrial IoT.
CP903083 3V 6400mAh Lithium Manganese Soft Pack Battery: High-Capacity Power for Decades of Unattended IoT Operation
When your field deployment plan spans 5 to 10 years, standard micro-power cells simply run out of juice too early, while heavy, rigid cylindrical batteries (like C or D cells) ruin your product's sleek mechanical profile. The CP903083 3V 6400mAh Lithium Manganese Dioxide LiMnO2 Soft Pack Battery resolves this classic engineering trade-off.
By packing a massive 6400mAh capacity into a slim 9.2mm profile, this primary soft pack battery is engineered to sustain high-power communication pulses and continuous sensor monitoring in space-constrained industrial enclosures.
Technical Specifications: Heavy-Duty Capacity, Compact Profile
Manufactured with high-purity raw materials and strict quality controls, the CP903083 provides the reliable energy output required by mission-critical hardware.
| Technical Parameter | Specification Value |
| Model Number | CP903083 |
| Battery Chemistry | Lithium Manganese Dioxide LiMnO2 |
| Nominal Voltage | 3.0V |
| Nominal Capacity | 6400mAh |
| Physical Dimensions | 9.2 x 30.0 x 83.5 mm (Thickness × Width × Length) |
| Unit Weight | Approx. 43.5g |
| Operating Temperature Range | -40°C to +60°C |
| Annual Self-Discharge Rate | ≤ 2% (stored at room temperature) |
Technical Specifications of 3V lithium pouch batteries
| Model | Nominal Voltage | Nominal Capacity | Standard Current | Max Continuous Current | Max Pulse Current | Max Dimensions | The Electrode Structure | Weight Approx |
| (V) | (mAh) | (mA) | ( mA) | (mA) | (mm) | (g) | ||
| CP073040 | 3 | 90 | 1 | 15 | 30 | 0.7*30*41 | Laminated | 1.3 |
| CP076045 | 3 | 230 | 2 | 100 | 150 | 0.7*60*45.5 | Laminated | 2.6 |
| CP102833 | 3 | 120 | 1 | 30 | 50 | 1.0*28.5*33.5 | Laminated | 1.2 |
| CP114752 | 3 | 540 | 1 | 100 | 200 | 1.15*47*52.5 | Laminated | 4.8 |
| CP155050 | 3 | 600 | 5 | 150 | 300 | 1.5*50*50 | Spiral | 6.5 |
| CP210619 | 3 | 25 | 0.25 | 3 | 8 | 2.1*6.5*19.5 | Laminated | 0.35 |
| CP223830 | 3 | 400 | 2 | 100 | 200 | 2.3*39*30 | Spiral | 3.6 |
| CP224147 | 3 | 900 | 1 | 500 | 1000 | 2.2*45.5*48 | Spiral | 7.5 |
| CP224642 | 3 | 920 | 2 | 50 | 90 | 2.2*46*42 | Laminated | 8.5 |
| CP301330 | 3 | 200 | 5 | 50 | 100 | 3.0*13.5*30.5 | Spiral | 2 |
| CP302752 | 3 | 950 | 5 | 300 | 500 | 3.0*27*52 | Spiral | 7.5 |
| CP302775 | 3 | 1450 | 5 | 300 | 500 | 3.0*27*75 | Spiral | 10.5 |
| CP303555 | 3 | 1350 | 5 | 500 | 1000 | 3.0*35*55 | Spiral | 10.5 |
| CP305050 | 3 | 1800 | 5 | 800 | 1200 | 3.1*50*51 | Spiral | 13.8 |
| CP332544 | 3 | 750 | 5 | 150 | 300 | 3.3*25*44 | Spiral | 6 |
| CP383047 | 3 | 1300 | 5 | 400 | 800 | 3.9*30*47 | Spiral | 9.5 |
| CP403555 | 3 | 1600 | 5 | 400 | 800 | 4.0*35*55 | Spiral | 12 |
| CP431520 | 3 | 220 | 5 | 200 | 300 | 4.3*15*20 | Spiral | 2 |
| CP451728 | 3 | 400 | 10 | 100 | 200 | 4.5*16.8*28.5 | Spiral | 3.5 |
| CP501728 | 3 | 450 | 10 | 100 | 200 | 5.0*16.8*28.5 | Spiral | 3.8 |
| CP502025 | 3 | 500 | 2 | 100 | 200 | 5.1*20*25 | Spiral | 4.5 |
| CP502030 | 3 | 600 | 5 | 150 | 300 | 5.2*20.5*30.5 | Spiral | 5 |
| CP502425 | 3 | 600 | 5 | 150 | 300 | 5.2*25*26 | Spiral | 4.8 |
| CP502440 | 3 | 1200 | 5 | 300 | 500 | 5.0*24*40.5 | Spiral | 9 |
| CP502495 | 3 | 3200 | 5 | 800 | 1600 | 5.2*24.5*95.5 | Spiral | 23 |
| CP505050 | 3 | 3000 | 10 | 1000 | 3000 | 5.0*50*51 | Spiral | 24 |
| CP505060 | 3 | 4300 | 10 | 1500 | 3000 | 5.2*51*61 | Spiral | 30 |
| CP521728 | 3 | 500 | 10 | 100 | 200 | 5.2*16.5*28.5 | Spiral | 4 |
| CP551728 | 3 | 520 | 10 | 100 | 300 | 5.5*16.8*28.5 | Spiral | 4 |
| CP583083 | 3 | 4000 | 10 | 1000 | 2000 | 5.8*30*83 | Spiral | 27 |
| CP601822 | 3 | 450 | 5 | 200 | 300 | 6.0*18*22 | Spiral | 3.8 |
| CP601967 | 3 | 1800 | 1 | 300 | 500 | 6.0*19*65 | Spiral | 13.5 |
| CP602429 | 3 | 1100 | 2 | 16.5 | 50 | 6.0*24*28.5 | Laminated | 8 |
| CP602429 | 3 | 900 | 1 | 300 | 500 | 6.0*24*28.5 | Spiral | 7 |
| CP602446 | 3 | 1600 | 5 | 400 | 800 | 6.0*24*46 | Spiral | 12 |
| CP653235 | 3 | 1800 | 5 | 800 | 1200 | 6.7*32*35 | Spiral | 13 |
| CP702030 | 3 | 900 | 1 | 300 | 500 | 7.0*20*30 | Spiral | 7 |
| CP702440 | 3 | 1600 | 10 | 500 | 1000 | 7.2*24*41 | Spiral | 11.5 |
| CP702446 | 3 | 2000 | 5 | 500 | 1000 | 7.2*25*47 | Spiral | 13 |
| CP702528 | 3 | 1100 | 5 | 300 | 500 | 7.0*25.5*28.5 | Spiral | 8 |
| CP703235 | 3 | 1800 | 5 | 800 | 1200 | 7.0*32*35 | Spiral | 13.5 |
| CP723434 | 3 | 1950 | 5 | 1000 | 2500 | 7.2*34*34 | Spiral | 14 |
| CP903083 | 3 | 6400 | 10 | 1000 | 2000 | 9.2*30*83.5 | Spiral | 43.5 |
| CP905078 | 3 | 10000 | 10 | 3000 | 5000 | 9.0*50*78 | Spiral | 70 |
| CP1003850 | 3 | 5200 | 10 | 1000 | 2000 | 10.0*38*50 | Spiral | 35 |
| CP1004040 | 3 | 4300 | 5 | 1000 | 1500 | 10.2*40.5*40.5 | Spiral | 27 |
| CP1005050 | 3 | 7500 | 10 | 1000 | 1500 | 10.5*52.5*52.5 | Spiral | 50 |
Why Hardware Designers Specify the CP903083 for Long-Term Deployments
1. Exceptional Energy Density in a 9.2mm Frame
Weighing only 43.5g, this battery bypasses heavy steel or plastic outer cans in favor of a specialized, aluminum-laminated foil pouch. This structural choice maximizes active chemical volume, delivering an outstanding energy-to-weight ratio that keeps your end product portable, flat, and easy to mount.
2. High-Capacity Buffer for Power-Hungry Telematics
With 6400mAh of on-board energy, this cell easily handles the heavy current draws required during cellular pings (NB-IoT, LTE-M, 5G), GPS cold starts, and active sensor sweeps. It eliminates the need to wire multiple smaller batteries in parallel, simplifying your PCB layout and reducing potential failure points.
3. All-Weather Environmental Resilience (-40°C to +60°C)
Industrial hardware cannot choose its climate. From sub-zero cold-chain transport container monitors to smart utility meters baking on outdoor walls under direct sunlight, the CP903083’s chemical formulation ensures a stable discharge curve and prevents sudden voltage drops under extreme temperatures.
4. Over 10 Years of Shelf & Operational Life
With a self-discharge rate of under 2% per year, the chemical passivation layer inside the CP903083 stays highly stable during long periods of inactivity. Your equipment can remain idle or in deep-sleep mode for years, yet wake up instantly with full voltage readiness when an event is triggered.
Targeted B2B Applications
The CP903083 is built for demanding primary-power applications where battery replacement is economically or logistically impossible:
Heavy-Duty GPS Tracking & Asset Management: Perfect for intermodal container trackers, trailer locators, and high-value cargo monitors requiring frequent daily location reports.
Active RFID Systems: Powers long-range industrial tracking transponders, real-time location systems (RTLS) in mining, and heavy yard management tags.
Industrial Utility & Smart Flow Meters: Serves as the primary or backup power source for gas, water, and heat meters, keeping data transmission online for up to a decade.
Portable Intelligent Instruments & Handheld Testers: Provides long-lasting, lightweight power for field gas detectors, rugged environmental sensors, and outdoor testing gear.
Smart Medical Machinery & Devices: Supplies high-capacity, stable power to portable clinical diagnostic equipment, medical backup units, and long-term mobile monitors.
Wireless Security & Commercial Intrusion Alarms: Powering high-draw alarm sirens, remote smart locks, and outdoor motion detection arrays.
SRAM Memory Backup Power: Guarantees absolute data retention in industrial automation computers, PLCs, and high-end server configurations.
Specialty Financial Devices & Smart Cards: Fits within slightly thicker handheld POS terminals, specialized high-security OTP tokens, and industrial smart cards.
Wireless Industrial Remote Controls: Powers heavy-duty crane controllers, mining machinery remotes, and marine steering interfaces.
Comprehensive B2B Customization & Support
We don't just supply cells; we build fully integrated power solutions tailored to your assembly line's specific workflow:
Custom Connectors & Leads: Supplied with pre-soldered JST, Molex, Hirose, or custom-specified wire leads and connectors to speed up your internal production.
Onboard Protection (PCM/BPS): Integrated circuit protection designed to prevent external short-circuits, over-discharge, and accidental charging.
Custom Multi-Cell Packs: Designed in series or parallel configurations to scale up capacity or voltage for complex electrical requirements.
Request Technical Datasheets, STEP Files, or Evaluation Samples
Ready to optimize your next-generation hardware design? Contact our engineering team today to receive detailed technical drawings, 3D STEP models, and custom wholesale pricing for your prototype runs.
[Contact Our Technical Sales Team] | [Request CP903083 Samples]
