CP702446 3V 2000mAh Lithium Manganese Soft Pack Battery: High-Density Power for Next-Gen IoT & GPS Tracking
When your hardware design demands a micro-profile without sacrificing energy capacity, standard cylindrical cells simply won’t fit. Enter the CP702446 3V 2000mAh Lithium Manganese Dioxide LiMnO2 Soft Pack Battery—an ultra-thin, high-performance pouch cell engineered to deliver robust, reliable power under extreme conditions.
With a nominal capacity of 2000mAh packed into a mere 7.2mm thickness, this flexible soft pack battery represents the sweet spot between structural versatility and long-term energy density.
Technical Specifications: Built for Precision Engineering
Every millimeter matters in modern hardware. The CP702446 is designed with tight tolerances and premium chemistry to ensure seamless integration into your PCB layouts.
| Parameter | Specification |
| Model | CP702446 |
| Chemistry | Lithium Manganese Dioxide LiMnO2 |
| Nominal Voltage | 3.0V |
| Nominal Capacity | 2000mAh |
| Dimensions | 7.2*25*47mm (Thickness × Width × Length) |
| Weight | Approx. 13.0g |
| Operating Temperature | -40°C to +60°C |
| Annual Self-Discharge Rate | ≤2% at room temperature |
Technical Parameters of 3V Lithium Manganese Soft Pack Batteries
| Model | Nominal Voltage | Nominal Capacity | Standard Current | Max Continuous Current | Max Pulse Current | Max Dimensions | The Electrode Structure | Weight Approx |
| (V) | (mAh) | (mA) | ( mA) | (mA) | (mm) | (g) | ||
| CP073040 | 3 | 90 | 1 | 15 | 30 | 0.7*30*41 | Laminated | 1.3 |
| CP076045 | 3 | 230 | 2 | 100 | 150 | 0.7*60*45.5 | Laminated | 2.6 |
| CP102833 | 3 | 120 | 1 | 30 | 50 | 1.0*28.5*33.5 | Laminated | 1.2 |
| CP114752 | 3 | 540 | 1 | 100 | 200 | 1.15*47*52.5 | Laminated | 4.8 |
| CP155050 | 3 | 600 | 5 | 150 | 300 | 1.5*50*50 | Spiral | 6.5 |
| CP210619 | 3 | 25 | 0.25 | 3 | 8 | 2.1*6.5*19.5 | Laminated | 0.35 |
| CP223830 | 3 | 400 | 2 | 100 | 200 | 2.3*39*30 | Spiral | 3.6 |
| CP224147 | 3 | 900 | 1 | 500 | 1000 | 2.2*45.5*48 | Spiral | 7.5 |
| CP224642 | 3 | 920 | 2 | 50 | 90 | 2.2*46*42 | Laminated | 8.5 |
| CP301330 | 3 | 200 | 5 | 50 | 100 | 3.0*13.5*30.5 | Spiral | 2 |
| CP302752 | 3 | 950 | 5 | 300 | 500 | 3.0*27*52 | Spiral | 7.5 |
| CP302775 | 3 | 1450 | 5 | 300 | 500 | 3.0*27*75 | Spiral | 10.5 |
| CP303555 | 3 | 1350 | 5 | 500 | 1000 | 3.0*35*55 | Spiral | 10.5 |
| CP305050 | 3 | 1800 | 5 | 800 | 1200 | 3.1*50*51 | Spiral | 13.8 |
| CP332544 | 3 | 750 | 5 | 150 | 300 | 3.3*25*44 | Spiral | 6 |
| CP383047 | 3 | 1300 | 5 | 400 | 800 | 3.9*30*47 | Spiral | 9.5 |
| CP403555 | 3 | 1600 | 5 | 400 | 800 | 4.0*35*55 | Spiral | 12 |
| CP431520 | 3 | 220 | 5 | 200 | 300 | 4.3*15*20 | Spiral | 2 |
| CP451728 | 3 | 400 | 10 | 100 | 200 | 4.5*16.8*28.5 | Spiral | 3.5 |
| CP501728 | 3 | 450 | 10 | 100 | 200 | 5.0*16.8*28.5 | Spiral | 3.8 |
| CP502025 | 3 | 500 | 2 | 100 | 200 | 5.1*20*25 | Spiral | 4.5 |
| CP502030 | 3 | 600 | 5 | 150 | 300 | 5.2*20.5*30.5 | Spiral | 5 |
| CP502425 | 3 | 600 | 5 | 150 | 300 | 5.2*25*26 | Spiral | 4.8 |
| CP502440 | 3 | 1200 | 5 | 300 | 500 | 5.0*24*40.5 | Spiral | 9 |
| CP502495 | 3 | 3200 | 5 | 800 | 1600 | 5.2*24.5*95.5 | Spiral | 23 |
| CP505050 | 3 | 3000 | 10 | 1000 | 3000 | 5.0*50*51 | Spiral | 24 |
| CP505060 | 3 | 4300 | 10 | 1500 | 3000 | 5.2*51*61 | Spiral | 30 |
| CP521728 | 3 | 500 | 10 | 100 | 200 | 5.2*16.5*28.5 | Spiral | 4 |
| CP551728 | 3 | 520 | 10 | 100 | 300 | 5.5*16.8*28.5 | Spiral | 4 |
| CP583083 | 3 | 4000 | 10 | 1000 | 2000 | 5.8*30*83 | Spiral | 27 |
| CP601822 | 3 | 450 | 5 | 200 | 300 | 6.0*18*22 | Spiral | 3.8 |
| CP601967 | 3 | 1800 | 1 | 300 | 500 | 6.0*19*65 | Spiral | 13.5 |
| CP602429 | 3 | 1100 | 2 | 16.5 | 50 | 6.0*24*28.5 | Laminated | 8 |
| CP602429 | 3 | 900 | 1 | 300 | 500 | 6.0*24*28.5 | Spiral | 7 |
| CP602446 | 3 | 1600 | 5 | 400 | 800 | 6.0*24*46 | Spiral | 12 |
| CP653235 | 3 | 1800 | 5 | 800 | 1200 | 6.7*32*35 | Spiral | 13 |
| CP702030 | 3 | 900 | 1 | 300 | 500 | 7.0*20*30 | Spiral | 7 |
| CP702440 | 3 | 1600 | 10 | 500 | 1000 | 7.2*24*41 | Spiral | 11.5 |
| CP702446 | 3 | 2000 | 5 | 500 | 1000 | 7.2*25*47 | Spiral | 13 |
| CP702528 | 3 | 1100 | 5 | 300 | 500 | 7.0*25.5*28.5 | Spiral | 8 |
| CP703235 | 3 | 1800 | 5 | 800 | 1200 | 7.0*32*35 | Spiral | 13.5 |
| CP723434 | 3 | 1950 | 5 | 1000 | 2500 | 7.2*34*34 | Spiral | 14 |
| CP903083 | 3 | 6400 | 10 | 1000 | 2000 | 9.2*30*83.5 | Spiral | 43.5 |
| CP905078 | 3 | 10000 | 10 | 3000 | 5000 | 9.0*50*78 | Spiral | 70 |
| CP1003850 | 3 | 5200 | 10 | 1000 | 2000 | 10.0*38*50 | Spiral | 35 |
| CP1004040 | 3 | 4300 | 5 | 1000 | 1500 | 10.2*40.5*40.5 | Spiral | 27 |
| CP1005050 | 3 | 7500 | 10 | 1000 | 1500 | 10.5*52.5*52.5 | Spiral | 50 |
Why Hardware Engineers Choose the CP702446
1. Ultra-Thin, Lightweight Form Factor
At just 7.2mm thick and weighing a mere 13g, the CP702446 utilizes a laminated aluminum foil pouch rather than a heavy metal casing. This dramatically reduces the overall weight of your final product while maximizing internal space efficiency.
2. Built for Extreme Climates (-40°C to +60°C)
From cold-chain logistics monitoring in sub-zero environments to asset tracking in scorching outdoor heat, this battery’s specialized electrolyte formula guarantees stable voltage output across a wide temperature spectrum.
3. Over 10 Years of Shelf Life
With an exceptionally low annual self-discharge rate of under 2%, the CP702446 minimizes chemical degradation. It remains ready to perform even after long periods of standby or inactive storage, making it ideal for critical infrastructure backup and long-deployment IoT nodes.
4. Superior Safety Profile
Unlike lithium polymer chemistry, LiMnO2 soft pack cells do not suffer from thermal runaway under normal operating conditions. The flexible pouch design acts as an inherent safety valve, neutralizing pressure build-ups safely and ensuring compliance with strict industrial safety standards.
Core Application Fields
The unique profile and high discharge reliability of the CP702446 make it the go-to power source for mission-critical, low-power wide-area network (LPWAN) applications:
GPS Tracking & Asset Location Systems: Provides the continuous current required for cellular/satellite pings and the long standby times needed for cargo, fleet, and container trackers.
Active RFID Tags: Powering long-range tracking tags in logistics, warehousing, and high-value asset management.
Smart Medical Devices: Reliable, lightweight power for portable diagnostic instruments, patch pumps, and wearable patient monitors.
Security & Intrusion Alarms: Ensures uninterrupted wireless sensor communication for home and industrial security systems.
Industrial IoT & Smart Metering: Providing decades-long reliable backup or primary power for flow meters, gas meters, and remote telemetry units (RTUs).
Memory Backup Power (SRAM): Safeguards critical data in industrial PCs, server mainboards, and high-end PLC modules.
Smart Cards & Financial Devices: Fits within slim form-factor payment terminals and OTP security display cards.
Portable Smart Instrumentation: Powering handheld testing equipment used in field operations.
OEM/ODM Customization Capabilities
As a leading manufacturer of primary lithium batteries, we understand that one size rarely fits all. We offer comprehensive customization options for the CP702446 to match your specific hardware requirements:
Custom Lead Wires & Connectors: JST, Molex, Hirose, or custom-soldered wire lengths.
PCM/BPS Integration: Custom protective circuitry for added over-discharge or short-circuit defense.
Custom Packaging & Labeling: Tailored branding, barcoding, and packaging layouts for seamless assembly-line integration.
Request a Technical Datasheet or Sample Pack
Ready to test the CP702446 in your next design cycle? Contact our engineering team today for technical drawings, 3D STEP files, and wholesale volume pricing.
