CR2320T 3V 130mAh High-Temperature Lithium Battery
- Omnergy
- China
- 15 days
- 750 million per year
High-performance CR2320T 3V 130mAh lithium battery by Omnergy. Wide temp range (-40°C to +85°C). Ultra-slim 2.0mm design for automotive & industrial IoT. Factory direct wholesale.
CR2320T 3V 130mAh High-Temperature Lithium Battery
Description of CR2320T 3V 130mAh: High-Stability Power for Space-Constrained Industrial Electronics
The CR2320T is an industrial-grade 3V Lithium Manganese Dioxide (Li/MnO2) battery designed for precision and endurance. With a 130mAh capacity packed into an ultra-slim 2.0mm profile, the CR2320T is the ideal power source for sophisticated electronics that require a low-clearance energy solution without compromising on thermal performance.
Technical Specifications of CR2320T button cell battery
| Feature | Data |
| Model | CR2320T (High-Temp Series) |
| Nominal Voltage | 3.0V |
| Nominal Capacity | 130mAh |
| Operating Temperature | -40°C to +85°C |
| Dimensions | 23.0mm x 2.0mm |
| Weight | Approx. 3.0g |
| Standard Discharge Current | 0.2mA |
More T-Type Button Cell Batteries
| Model | Nominal Voltage (V) | Nominal Capacity (mAh) | Nominal Current (mA) | Maximum Continuous Current (mA) | Maximum Pluse Current (mA) | Max Dimension (mm) | Working Temperature (℃） | Weight (g) |
| CR1225T | 3 | 50 | 0.1 | 2 | 5 | Φ12.5*2.5 | -40～85 | 0.9 |
| CR1620T | 3 | 70 | 0.1 | 3 | 8 | Φ16.0*2.0 | -40～85 | 1.3 |
| CR1632T | 3 | 120 | 0.2 | 3 | 8 | Φ16.0*3.2 | -40～85 | 2 |
| CR2016T | 3 | 80 | 0.1 | 5 | 15 | Φ20.0*1.6 | -40～85 | 2.3 |
| CR2025T | 3 | 150 | 0.2 | 5 | 15 | Φ20.0*2.5 | -40～85 | 2.6 |
| CR2032T | 3 | 220 | 0.2 | 5 | 15 | Φ20.0*3.2 | -40～85 | 3.2 |
| CR2320T | 3 | 130 | 0.2 | 6 | 20 | Φ23.0*2.0 | -40～85 | 3 |
| CR2330T | 3 | 260 | 0.2 | 6 | 20 | Φ23.0*3.0 | -40～85 | 4 |
| CR2354T | 3 | 520 | 0.4 | 6 | 20 | Φ23.0*5.4 | -40～85 | 6.9 |
| CR2430T | 3 | 270 | 0.2 | 7 | 25 | Φ24.5*3.0 | -40～85 | 4.5 |
| CR2450T | 3 | 600 | 0.4 | 7 | 25 | Φ24.5*5.0 | -40～85 | 6.8 |
| CR2477T | 3 | 1000 | 0.6 | 7 | 25 | Φ24.5*7.7 | -40～85 | 10.5 |
| CR3032T | 3 | 500 | 0.4 | 10 | 30 | Φ30.0*3.2 | -40～85 | 6.8 |
| CR3832T | 3 | 850 | 0.8 | 20 | 75 | Φ38.0×3.2 | -40～85 | 11 |
Key Competitive Advantages of Omnergy CR2320T
■ Optimized Slim Form Factor (2.0mm)
In the world of PCB design, every millimeter counts. The CR2320T offers a significant height advantage over the CR2330 or CR2354, allowing for ultra-thin housing in smart devices while maintaining the broad 23mm contact surface for superior mounting stability.
■ Exceptional Heat Resistance (-40°C to +85°C)
While standard CR2320 cells are limited to commercial environments, the Omnergy CR2320T features our advanced heat-resistant electrolyte. This ensures reliable data retention and sensor operation in automotive cabins, industrial ovens, and high-heat manufacturing zones.
■ Long-Term Power Reliability
Our CR2320T is built with ultra-pure lithium and a proprietary sealing process. It boasts a low self-discharge rate (less than 2% per year), ensuring that your devices remain operational even after years of inactivity in backup mode.
■ B2B Manufacturing & Customization
Omnergy provides full-scale OEM/ODM support for the CR2320T. We specialize in adding:
• Through-hole solder pins for permanent PCB mounting.
• SMT-compatible tabs for automated assembly.
• Custom wire harnesses with connectors.
________________________________________
Strategic Applications
• Automotive Tech: Remote Keyless Entry (RKE), infotainment memory backup, and internal clock (RTC) support.
• Industrial IoT: Ultra-thin asset tracking tags and environmental sensor nodes.
• Smart Security: Slim electronic locks, safe-box control panels, and tamper sensors.
• Medical Devices: Miniature diagnostic tools and patient monitoring patches.
________________________________________
FAQ Section
Q: Why use CR2320T instead of a standard CR2032?
A: The CR2320T has a larger diameter (23mm vs 20mm) but a much slimmer profile (2.0mm vs 3.2mm). If your PCB design has height restrictions but allows for a wider footprint, the CR2320T provides a more stable physical mount and specialized high-temperature resistance that standard CR2032 cells lack.
Q: Is the Omnergy CR2320T compatible with automated SMT pick-and-place?
A: Yes. When ordered with our custom SMT solder tabs, the CR2320T is supplied in heat-resistant trays packaging, specifically designed for high-speed automated production lines.
Q: What certifications does the CR2320T hold?
A: All Omnergy CR2320T batteries are fully compliant with UL1642, RoHS, REACH, and UN38.3 standards, ensuring safe global shipping and integration into international markets.
