CP502025 LiMnO₂ Lithium Pouch Cell
- Omnergy
- 中国
- 15 days
- 1000 million per year
3V lithium manganese soft-pack battery, disposable soft-pack battery, CP502025 specification, ultra-thin battery, IoT device battery, long-life miniature battery, custom lithium manganese soft-pack batteries available.
Technical Parameters
| Model | Nominal Voltage | Nominal Capacity | Standard Current | Max Continuous Current | Max Pulse Current | Max Dimensions | The Electrode Structure | Weight Approx |
| (V) | (mAh) | (mA) | ( mA) | (mA) | (mm) | (g) | ||
| CP073040 | 3 | 90mAh | 1mA | 15mA | 30mA | 0.7*30*41 | Laminating Structure | 1.3 |
| CP076045 | 3 | 230mAh | 2mA | 100mA | 150mA | 0.7*60*45.5 | Laminating Structure | 2.6 |
| CP102833 | 3 | 120mAh | 1mA | 30mA | 50mA | 1.0*28.5*33.5 | Laminating Structure | 1.2 |
| CP114752 | 3 | 540mAh | 1mA | 100mA | 200mA | 1.15*47*52.5 | Laminating Structure | 4.8 |
| CP155050 | 3 | 600mAh | 5mA | 150mA | 300mA | 1.5*50*50 | Winding Structure | 6.5 |
| CP210619 | 3 | 25mAh | 0.25mA | 3mA | 8mA | 2.1*6.5*19.5 | Laminating Structure | 0.35 |
| CP223830 | 3 | 400mAh | 2mA | 100mA | 200mA | 2.3*39*30 | Winding Structure | 3.6 |
| CP224147 | 3 | 900mAh | 1mA | 500mA | 1000mA | 2.2*45.5*48 | Winding Structure | 7.5 |
| CP224642 | 3 | 920mAh | 2mA | 50mA | 90mA | 2.2*46*42 | Laminating Structure | 8.5 |
| CP301330 | 3 | 200mAh | 5mA | 50mA | 100mA | 3.0*13.5*30.5 | Winding Structure | 2 |
| CP302752 | 3 | 950mAh | 5mA | 300mA | 500mA | 3.0*27*52 | Winding Structure | 7.5 |
| CP302775 | 3 | 1450mAh | 5mA | 300mA | 500mA | 3.0*27*75 | Winding Structure | 10.5 |
| CP303555 | 3 | 1350mAh | 5mA | 500mA | 1000mA | 3.0*35*55 | Winding Structure | 10.5 |
| CP305050 | 3 | 1800mAh | 5mA | 800mA | 1200mA | 3.1*50*51 | Winding Structure | 13.8 |
| CP332544 | 3 | 750mAh | 5mA | 150mA | 300mA | 3.3*25*44 | Winding Structure | 6 |
| CP383047 | 3 | 1300mAh | 5mA | 400mA | 800mA | 3.9*30*47 | Winding Structure | 9.5 |
| CP403555 | 3 | 1600mAh | 5mA | 400mA | 800mA | 4.0*35*55 | Winding Structure | 12 |
| CP431520 | 3 | 220mAh | 5mA | 200mA | 300mA | 4.3*15*20 | Winding Structure | 2 |
| CP451728 | 3 | 400mAh | 10mA | 100mA | 200mA | 4.5*16.8*28.5 | Winding Structure | 3.5 |
| CP501728 | 3 | 450mAh | 10mA | 100mA | 200mA | 5.0*16.8*28.5 | Winding Structure | 3.8 |
| CP502025 | 3 | 500mAh | 2mA | 100mA | 200mA | 5.1*20*25 | Winding Structure | 4.5 |
| CP502030 | 3 | 600mAh | 5mA | 150mA | 300mA | 5.2*20.5*30.5 | Winding Structure | 5 |
| CP502425 | 3 | 600mAh | 5mA | 150mA | 300mA | 5.2*25*26 | Winding Structure | 4.8 |
| CP502440 | 3 | 1200mAh | 5mA | 300mA | 500mA | 5.0*24*40.5 | Winding Structure | 9 |
| CP502495 | 3 | 3200mAh | 5mA | 800mAh | 1600mA | 5.2*24.5*95.5 | Winding Structure | 23 |
| CP505050 | 3 | 3000mAh | 10mA | 1000mA | 3000mA | 5.0*50*51 | Winding Structure | 24 |
| CP505060 | 3 | 4300mAh | 10mA | 1500mA | 3000mA | 5.2*51*61 | Winding Structure | 30 |
| CP521728 | 3 | 500mAh | 10mA | 100mA | 200mA | 5.2*16.5*28.5 | Winding Structure | 4 |
| CP551728 | 3 | 520mAh | 10mA | 100mA | 300mA | 5.5*16.8*28.5 | Winding Structure | 4 |
| CP583083 | 3 | 4000mAh | 10mA | 1000mA | 2000mA | 5.8*30*83 | Winding Structure | 27 |
| CP601822 | 3 | 450mAh | 5mA | 200mA | 300 mA | 6.0*18*22 | Winding Structure | 3.8 |
| CP601967 | 3 | 1800mAh | 1mA | 300mA | 500 mA | 6.0*19*65 | Winding Structure | 13.5 |
| CP602429 | 3 | 1100mAh | 2mA | 16.5mA | 50 mA | 6.0*24*28.5 | Laminating Structure | 8 |
| CP602429 | 3 | 900mAh | 1mA | 300mA | 500 mA | 6.0*24*28.5 | Winding Structure | 7 |
| CP602446 | 3 | 1600mAh | 5mA | 400mAh | 800mA | 6.0*24*46 | Winding Structure | 12 |
| CP653235 | 3 | 1800mAh | 5mA | 800mAh | 1200mA | 6.7*32*35 | Winding Structure | 13 |
| CP702030 | 3 | 900mAh | 1mA | 300mAh | 500mA | 7.0*20*30 | Winding Structure | 7 |
| CP702440 | 3 | 1600mAh | 10mA | 500mAh | 1000mA | 7.2*24*41 | Winding Structure | 11.5 |
| CP702446 | 3 | 2000mAh | 5mA | 500mAh | 1000mA | 7.2*25*47 | Winding Structure | 13 |
| CP702528 | 3 | 1100mAh | 5mA | 300mAh | 500mA | 7.0*25.5*28.5 | Winding Structure | 8 |
| CP703235 | 3 | 1800mAh | 5mA | 800mAh | 1200mA | 7.0*32*35 | Winding Structure | 13.5 |
| CP723434 | 3 | 1950mAh | 5mA | 1000mAh | 2500mA | 7.2*34*34 | Winding Structure | 14 |
| CP903083 | 3 | 6400mAh | 10mA | 1000mA | 2000mA | 9.2*30*83.5 | Winding Structure | 43.5 |
| CP905078 | 3 | 10000mAh | 10mA | 3000mA | 5000mA | 9.0*50*78 | Winding Structure | 70 |
| CP1003850 | 3 | 5200mAh | 10mA | 1000mA | 2000 mA | 10.0*38*50 | Winding Structure | 35 |
| CP1004040 | 3 | 4300mAh | 5mA | 1000mA | 1500 mA | 10.2*40.5*40.5 | Winding Structure | 27 |
| CP1005050 | 3 | 7500mAh | 10mA | 1000mA | 1500 mA | 10.5*52.5*52.5 | Winding Structure | 50 |
CP502025 3V Disposable Lithium Manganese Soft Pack Battery: Designed for Ultimate Space Efficiency and Long-Lasting Power
In today's world of miniaturized and intelligent product design, traditional cylindrical or button batteries often become a spatial bottleneck. The CP502025 3V disposable lithium manganese soft pack battery is born from this need, redefining the power supply standard for compact devices with its ultra-thin soft pack form factor, providing a durable, stable, and reliable energy core for your innovations.
Say Goodbye to Bulk, Embrace Slim and Free Design
The CP502025 utilizes advanced laminated soft pack technology, with dimensions of only 5.0mm (thickness) x 20mm (width) x 25mm (height). Its ultra-thin characteristics allow it to be easily embedded under the PCB board or within the device's layers, freeing up valuable design space. It is the ideal choice for ultra-thin card devices, miniature sensors, and smart wearable products.
Long-Lasting Power, Protecting Critical Data
As a disposable battery with a lithium manganese (Li-MnO2) chemical system, the CP502025 offers significant advantages:
High Energy Density: Provides a longer service life than traditional batteries of the same size.
Excellent Voltage Stability: Maintains a nearly constant 3V voltage output throughout the entire discharge cycle, ensuring stable operation of electronic components.
Ultra-Low Self-Discharge: Extremely low annual self-discharge rate, meeting storage and standby requirements for up to 10 years, making it a reliable power source for backup power and low-power devices.
Wide Temperature Range: Operates normally in a wide temperature range from -20°C to +60°C, adapting to harsh environments.
Safe, Reliable, and Widely Applicable
The battery has multiple built-in safety mechanisms and has passed rigorous certifications, eliminating the risk of leakage. Its soft pack structure offers better impact and vibration resistance. Main application areas include:
Internet of Things (IoT): Smart tags, environmental sensors, asset trackers.
Medical Electronics: Disposable medical patches, portable monitoring devices.
Consumer Electronics: Smart cards, electronic pens, miniature remote controls.
Industrial Control: Backup clock power supply, industrial control sensor modules. Upgrade your design today!
If you're looking for the ultimate power solution for next-generation, miniaturized, and long-lasting electronic devices, the CP502025 3V lithium manganese soft-pack battery is the perfect partner. It's not just a battery; it's the cornerstone for achieving product innovation and reliability.
